Heats and coolsR454B
Mia NY, Single-zone outdoor unit
9K Outdoor Unit, 115 V
A person checks this pairing before it ships.
Rebates for this unitUtility and state programs change by ZIP code.
- Ships to all 50 states. If anything arrives damaged, we handle the claim.
- New units from an authorized Cooper & Hunter dealer, with the full factory warranty.
- All sales are final. Not sure about the size? Call (417) 812-0015 before you order.
Rated performance
From the spec sheet on file for model CH-RLS06MIA-115VO. Every other figure is in the full spec sheet below.
- Capacity
9,000BTU/h
Cooling runs 2,200 to 9,900 BTU/h
- Efficiency
21.5SEER2
Bar on the catalog's 14 to 28 range
- Heating
5°F
Lowest outdoor temperature, manufacturer rating
- EER2
12.5
Full-load cooling efficiency
- Power
115V
- Cooling
- 5 to 122 °F
- Heating
- 5 to 75 °F
Why this outdoor unit
From the feature list on file for model CH-RLS06MIA-115VO.
- Auto-Swing for horizontal louvers
- Smart Kit Ready
- Turbo Mode
- Follow Me Mode
- Smart kit Included
Specifications
The full spec sheet
Every value on file for model CH-RLS06MIA-115VO, with units.
Capacity
5 values| Nominal capacity | 6,000 | BTU/h |
|---|---|---|
| Rated cooling capacity | 9,000 | BTU/h |
| Cooling capacity range | 2,200 to 9,900 | BTU/h |
| Rated heating capacity (47°F) | 10,000 | BTU/h |
| Heating capacity range (47°F) | 4,200 to 10,200 | BTU/h |
From the Cooper & Hunter spec sheet.
Electrical
4 values| Voltage | 115 | V |
|---|---|---|
| Phase | 1 | ph |
| Frequency | 60 | Hz |
| Operating voltage range | 103.5 to 126.5 | V |
From the Cooper & Hunter spec sheet.
Refrigerant and piping
3 values| Refrigerant | R-454B | |
|---|---|---|
| Pre-charged for line length up to | 25 | ft |
| Additional charge per extra foot, 1/4 in. liquid line | 0.16 | oz/ft |
From the Cooper & Hunter spec sheet.
Operating range
2 values| Outdoor operating range, cooling | 5 to 122 | °F |
|---|---|---|
| Outdoor operating range, heating | 5 to 75 | °F |
From the Cooper & Hunter spec sheet.
Approved pairings
Indoor heads approved for this unit.
This outdoor unit runs one indoor head. This is the head approved for it by Cooper & Hunter.
| Unit | Size |
|---|---|
 6K Wall MountCH-RLS06MIA-115VI | 6K BTU |
Rebates
Heat pump rebates by ZIP code
Utility and state programs change by ZIP code and can be large. Enter yours to see the programs on file for this model.
See the biggest programs by stateAbout this outdoor unit
What it is and what it needs.
The Cooper & Hunter 9K Outdoor Unit is a 9K BTU single-zone outdoor unit: it runs one matching indoor head. 1 indoor unit is approved for it by the manufacturer and listed on this page.
It runs on 115 V and uses R454B refrigerant. It is rated SEER2 21.5.
Call before you order.Sizing, pairings, line set lengths and rebates.
Monday to Friday, 8 AM to 5 PM Central
We are in Mountain Grove, Missouri.
Send a messageQuestions
Before you order
Anything else, call (417) 812-0015. Monday to Friday, 8 AM to 5 PM Central.
Is this the whole system?
This is the outdoor unit (condenser). Pair it with one of the approved indoor units listed above. Line sets and brackets are quoted with your order; call and we add them.
Can I install it myself?
Mounting, wiring and running the line set are within reach of a capable DIYer. The refrigerant connection and vacuum should be done by a licensed HVAC technician in most states, and manufacturer warranties usually require it. We can point you to an installer in your area.
What if I am not sure about the size?
Room size, ceiling height, insulation, windows and sun exposure all change the answer. Call (417) 812-0015 with the room details and we will confirm the BTU rating before you order.
Can I return it?
No. All sales are final, so size it right first: the builder and the sizing guide are free, and a person confirms the pairing on every order. If anything arrives damaged, we handle the claim for you, and defects are covered by the manufacturer warranty.
What refrigerant does it use?
R454B. Match it to any existing equipment or line set you plan to reuse; refrigerants are not interchangeable.
Reviews
From verified buyers only
No reviews for this unit yet.
We publish reviews from verified orders only. Buyers are invited to write one after delivery, and a person reads each review before it appears here.
Not sure about the size? Check it in the builder.
The builder sizes each room and shows only approved Cooper & Hunter systems. All sales are final, so size it right first.
Monday to Friday, 8 AM to 5 PM Central
